With sharp traditional sonar and bright ClearVü sonar, fish will have nowhere to hide.
With sonars' rich, high-contrast color ranges scanning, distinguishing targets and structures has never been easier.
The ECHOMAP UHD2 is compatible with a wide variety of Garmin transducers for two types of sonar: Garmin ClearVü and traditional scanning sonars.
Know the waters you navigate like you grew up fishing in them with optional Garmin Navionics+™ and Garmin Navionics Vision+™ marine mapping.< /p>
If you have another compatible ECHOMAP UHD2 chartplotter on your boat, the 5″ and 7″ models can wirelessly share information such as sonar images, waypoints and routes with each other .
Integrated Wi-Fi connectivity , który umożliwia połączenie z bezpłatną i kompletną aplikacją ActiveCaptain, aby uzyskać dostęp do funkcji n OneChart™, smart notifications, software updates, data from the Garmin Quickdraw™ community and much more.
Box contents:
ECHOMAP UHD2 52cv
Przetwornik GT20-TM
Kabel zasilający/do transmisji danych
Podparcie uchylne
Wsparcie dla montażu podtynkowego
Elementy montażowe
Documentation
Physical and performance characteristics
UNIT DIMENSIONS (WIDTH/HEIGHT/DEPTH)18.8 x 12.2 x 6.2 cm (7, 4″ x 4.8 x 2.4″)SCREEN KEYSSCREEN SIZE (WIDTH/HEIGHT)10.9 x 6.6 cm (4.3″ x 2.6″)SCREEN RESOLUTION (WIDTH/HEIGHT) 800 x 480 pixelsDISPLAY TYPEWVGA, IPSWEIGHT0.5kg (1.1lb)WATER RESISTANCE RATINGIPX7MOUNTING OPTIONSSurface or Flushmount
Maps and Memory
OBSŁUGA KART DANYCH1 karta microSD™; maksymalny rozmiar 32 GBWAYPOINTS 5000 TRACK POINTS 50000 TRACK POINTS 50 zapisanych śladów TRASY 100
Czujniki
WBUDOWANY ODBIORNIK 5 Hz KOMPATYBILNY Z GPS WAAS
Opcjonalna obsługa map
BLUECHART G3BLUECHART G3 VISIONGARMIN NAVIONICS+™GARMIN CONTIONICS QUICK3™ >Chartplotter FeaturesACTIVECAPTAIN-YHTEENSOPIVA
Sounder Specifications and Features
SHOWS SOUNDERPOWER OUTPUT500 WTRADITIONAL SOUNDER (DUAL BEAM/FREQUENCY)Integrated (Single Channel CHIRP, 70/83/200 kHz, low, high, and mid-frequency CHIRP)CLEARVÜ260/455/800kHz built-in
Connections
4-PIN TRANSDUCER PORTS1GARMIN WI-FI® NETWORK (LOCAL CONNECT)
Electrical
POWER INPUT9 to 18VdcTYPICAL CURRENT CONSUMPTION AT 12VDC1AMAXIMUM CURRENT CONSUMPTION AT 12VDC1.5AMAXIMUM POWER CONSUMPTION AT 10VDC
18W
